5 AXIS CNC

Quick cnc 5 axis cnc router K1212-5A
We offer the industry’s most advanced and comprehensive selection of 5-axis machine configurations to give you the best cost of ownership as well as endless part-processing capabilities.with 5 axis cnc router you can process five sides of a part in a single setup.
According to the products you are processing, you can choose one table or double tables.

Request A Quote

INQUIRY

Product Description

We offer the industry’s most advanced and comprehensive selection of 5-axis machine configurations to give you the best cost of ownership as well as endless part-processing capabilities.with 5 axis cnc router you can process five sides of a part in a single setup.
According to the products you are processing, you can choose one table or double tables

Send Inquiry

Video


Parameter

ModelK1212-5A
X-Y-Z   axis working area1200*1100*800mmOR 1200*1100*800mm*2
Machine   accuracy0.2mm
Repetition   accuracy0.0254mm
X-Y   movementrack and   pinion,gear drive/Taiwan
Z   movementball   screw drive/Taiwan
Guidelinear 30   square/Taiwan
RackHigh   precision 1.5M rack
Max.speed0-40m/min
Max.cutting   speed0-20m/min
Spindle   powerChina 9KW   ATC spindle
5 axis   headDEMAS
Inverter   powerFulling   inverter
Tool   magazine8 pcs auto   tool changers
Drive   motorSyntec   servo motor
TableAluminium   T-slot table
ReducerShimpo
Working   voltageAC380V/50Hz,3-phase
Command   codeG code, u00, mmg, plt,nc
ColletER32    3.175-12.7
ControlsSYNTEC 5   AXIS control system
 Optional
  1. Vacuum   table2.Vacuum

  2. pump3.double   working table


Accessories and Advantage

  • 5 AXIS DEMAS head

The high-performance electrospindles allow a host of different materials (plastic, resin, compound and aluminium) to be machined.

  • Syntec controller

Specific 5-axis SYNTEC controller for woodworking has multi-five axis compensation, Rotation tool center point feature (RTCP) and various serial communication methods such as Mechatrolink III, Mechatrolink II, EtherCAT, RTEX. With powerful 5-axis function and various serial communication methods, clients can choose more flexible.

  • Servo System

Equipped with many kinds of motor Multiple encoder communication interface support Fast and accurate processing through high speed serial communication and host controller

  • 9KW automactic tool changing spindle

Large magazine capacity for performing all types of machining operation


Quick cnc 5 axis cnc router K1212-5A (4).jpg

Send Inquiry

Application

Advertising industry:Signage, Logo ,Badges, Display board, Meeting sign board, Billboard,Advertising filed, Sign making,Acrylic engraving and cutting, Crystal word making, Blaster molding and other advertising materials derivatives making.

Wood furniture industry:Doors, Cabinets, Tables, Chairs, Wave plate, Fine pattern, Guitar....

Artwork and Decoration:wood crafts, gift box, jewelry box.

Other:Relief sculpture and 3D engraving and Cylindrical object.
